SITOP smart power supply

• Заказные данные
  (4)
• Информационные материалы

  Информационные материалы



  The 24 V power supply units from the SITOP range are optimized for industrial use and operate on the switched-mode principle. Due to the precisely regulated output voltage, the devices are even suitable for the connection of sensitive sensors. Different versions are available depending on the output current and field of application.

  SITOP smart

  SITOP smart does not require much space on the standard mounting rail and offers a high level of functionality.

  Thanks to the extra power, 1.5 times the rated current for 5 seconds, large loads can also be switched on without any problems.

  Особенности

  • High efficiency
  • Narrow width and easy installation
  • Exact output voltage and low residual ripple
  • Integrated short-circuit protection and safe electrical separation
  • National and international approvals
  • No release of silicone

  Технические данные

  Article No.		6EP1334-2BA20	6EP1336-2BA10	6EP1434-2BA10	6EP1436-2BA10
  Product brand name		SITOP smart	SITOP smart	SITOP smart	SITOP smart
  Short product code		PSU100S	PSU100S	PSU300S	PSU300S
  Product designation		Stabilized power supply 1-phase	Stabilized power supply 1-phase	Stabilized power supply 3-phase	Stabilized power supply 3-phase
  Rated output current	A	10	20	10	20
  Rated output voltage for DC	V	24	24	24	24
  Total tolerance, static ±	%	3	3	3	3
  Line frequency range	Hz	47 ... 63	47 ... 63	47 ... 63	47 ... 63
  Degree of protection		IP20	IP20	IP20	IP20
  Environmental category acc. to IEC 60721-3-3		Climate class 3K3, without condensation	Climate class 3K3, without condensation	Climate class 3K3, without condensation	Climate class 3K3, without condensation
  Ambient temperature, during
  storage	°C (°F)	-40 ... +85 (-40 ... +185)	-40 ... +85 (-40 ... +185)	-40 ... +85 (-40 ... +185)	-40 ... +85 (-40 ... +185)
  transport	°C (°F)	-40 ... +85 (-40 ... +185)	-40 ... +85 (-40 ... +185)	-40 ... +85 (-40 ... +185)	-40 ... +85 (-40 ... +185)
  operation	°C (°F)	-25 ... +70 (-13 ... +158)	0 ... 70 (32 ... 158)	0 ... 70 (32 ... 158)	0 ... 70 (32 ... 158)
  Width	mm (In)	70 (2.76)	115 (4.53)	90 (3.54)	90 (3.54)
  Height	mm (In)	125 (4.92)	145 (5.71)	145 (5.7!)	145 (5.71)
  Depth	mm (In)	120 (4.72)	150 (5.91)	150 (5.91)	150 (5.91)
  Net weight	kg (lb)	0.8 (1.76)	2.4 (5.29)	1.6 (3.53)	1.6 (3.53)
  Certificate of suitability		CB, CE, cCSAus, cULus	CB, CE, cCSAus, cULus	CB, CE, cCSAus, cULus	CB, CE, cCSAus, cULus





  Дальнейшая информация

  You can find additional information in Catalog KT 10.1, in the Siemens Industry Mall or on the Internet at:

  http://www.siemens.com/industrymall

  http://www.siemens.com/sitop
